MRCOOL DIY 12,000 BTU 1 Ton Ductless Mini-Split Wall Mounted Air Handler - 230V/60Hz - DIY-12-HP-WMAH-230B
1-844-463-9787
Free Shipping.
Choose the DIY 12k BTU 1 Ton Ductless Mini-Split Wall Mounted Air Handler for the most rewarding home improvement project that you can do essentially all by yourself. This unit can cover around 500 square feet, making it perfect for cooling a room in your home to your exact specifications or for additional heating and cooling power in a multi-zone setup. It’s easy to install, too! Just choose the best location to mount it, then connect it to the condenser using the DIY’s pre-charged line sets. You’ll save money before the system is even up and running! After you get this unit installed, there’s a lot of rest and relaxation headed your way thanks to modes like AUTO, DRYING, SLEEP, and many others. This air handler comes with a Smart HVAC Controller, which allows you to link the air handler to your phone so you can enjoy better control and a wider variety of features. You can rest easy knowing that this unit is covered by a 5 year parts warranty when you register your product online. This DIY 12k BTU 1 Ton Ductless Mini-Split Wall-Mounted Air Handler will treat you to flawless indoor comfort for years to come.
|
BULLET 1 |
Easy DIY Installation |
|
BULLET 2 |
Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion |
|
BULLET 3 |
Energy Efficient DC Inverter |
|
BULLET 4 |
R-410A environmentally friendly refrigerant |
|
BULLET 5 |
Systems include our SmartHVAC WiFi Control Module with improved setup and enhanced functionality for Apple and Android smart devices. Works with Amazon Alexa. Works with Google Assistant. |
|
COOLING CAPACITY |
12000 BTU |
|
HEATING CAPACITY |
12000 BTU |
|
VOLTAGE |
208-230 V |
|
PHASE |
1 |
|
CYCLE |
60 Hz |
|
MAX FUSE BREAKER |
15 A |
|
MIN CIRCUIT AMPACITY |
3 AMP |
|
MOUNT TYPE |
Wall |
|
COLOR |
White |
|
COLOR FAMILY |
White |
|
REFRIGERANT TYPE |
R-410A |
|
DECIBEL RATING |
31/37.5/45 dBA |
|
DECIBEL RATING LOW |
31 dBA |
|
DECIBEL RATING HIGH |
45 dBA |
|
AIR FLOW DIRECTION |
4-way |
|
NUMBER OF SPEEDS |
4 (Variable) |
|
OSCILLATION |
Yes |
|
INVERTER |
Yes |
|
MAX LINESET LENGTH |
75ft Max |
|
LIQUID LINE FITTING |
3/8 in |
|
LIQUID LINE SIZE |
1/4 in |
|
SUCTION LINE FITTING |
5/8 in |
|
SUCTION LINE SIZE |
1/2 in |
|
CONTROL TYPE |
LED |
|
FILTER TYPE |
Washable |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
No |
|
LOW VOLTAGE COMPENSATION |
No |
|
OVERLOAD PROTECTION |
Yes |
|
ADJUSTABLE THERMOSTAT |
Yes |
|
FAN ONLY OPTION |
Yes |
|
QUIET MODE |
Yes |
|
SLEEP MODE |
No |
|
AUTO COOL |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
WORKS WITH IOS |
Yes |
|
WORKS WITH ANDROID |
Yes |
|
REMOTE CONTROL INCLUDED |
Yes |
|
UL RECONIZED |
No |
|
UL LISTED |
No |
|
CSA LISTED |
Yes |
|
CSA CERTIFIED |
Yes |
|
ETL LISTED |
No |
|
ETL CERTIFIED |
No |
|
ENERGY STAR COMPLIANT |
No |
|
ENERGY STAR CERTIFIED |
No |
|
AHRI CERTIFIED |
Yes |
|
HAS BATTERIES |
Yes |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS AEROSOL |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
PROPOSITION 65 WARNING |
Yes |
|
RESTRICTED STATES |
GU PR;VI |
|
NET DEPTH |
7.44 |
|
NET HEIGHT |
11.69 |
|
NET WIDTH |
31.57 |
|
NET WEIGHT |
19.18 |
|
GROSS DEPTH |
17.52 |
|
GROSS HEIGHT |
14.17 |
|
GROSS WIDTH |
37.6 |
|
GROSS WEIGHT |
37.04 |
|
IMAGE 1 |
|
|
IMAGE 2 |
|
|
IMAGE 3 |
|
|
IMAGE 4 |
|
|
BROCHURE |
|
|
INSTALL MANUAL |
|
|
OWNER MANUAL |
|
|
TECHNICAL MANUAL |
|
|
AHRI CERTS |
|
|
ENERGY GUIDE CERTS |
 |
